Palmer Active 2-channel DI box

1.729,00 kr.
Inkl. moms
PAN 04 A

The Palmer PAN04A is 2-channel DI box for feeding asymmetrical and high impedance electric instrument signals into a mixing desk_s microphone inputs. It delivers a transformer balanced, low impedance signal to the outputs and eliminates mains hum and interference caused by ground loops. The active switch leaves the frequency response unaffected and achieves a high dynamic range. In addition to 6.35 mm direct outputs and -30 dB switchable input attenuation, the DI box also features a mono output that sums both channels. The PAN04A is designed to be exceptionally robust and is suitable for both stage and studio. It can be powered with 9 to 24 V DC mains adapters or phantom power when two outputs are connected to a mixer.

Antal
På fjernlager

Ref: PAN04A

  • Active 2-channel DI box with premium balancing transformers
  • 10_40 kHz frequency response, high dynamic response
  • -30 dB input attenuation, switchable
  • Ground lift switch for each output
  • Balanced mono summed output
  • Can be powered with 9 to 24 V DC mains adapters or phantom power

Product typeDI boxes
Typeactive
Channels2
Inputs2
Input connectors6.3 mm jack
Max. input level+ 45 dBu
Input impedance1M Ohm(s)
Number of outputs3
THRU outputs/channel1
Output connectors6.3 mm jack
Output connectorsXLR
Max. output level+ 11 dBu
Output impedance200 Ohm(s)
Frequency response10 - 40000
Transformer balancedYes
Ratio1 : 1
Controlsattenuation
Controlsground lift
Cabinet materialsheet steel
Cabinet surfacePowder coated
Width116 mm
Depth110 mm
Height45 mm
Weight0,47 kg
Palmer
PAN04A

Specifikke referencer
