. CC Pro Shop 10´´ 2-vejs koax-højttaler - SP-310CX Monacor .
10´´ 2-vejs koax-højttaler - SP-310CX Monacor
search
  • 10´´ 2-vejs koax-højttaler - SP-310CX Monacor
  • 10´´ 2-vejs koax-højttaler - SP-310CX Monacor

MONACOR 10´´ 2-vejs koax-højttaler - SP-310CX

1.579,00 kr.
Inkl. moms
Professional 2-way coaxial PA speaker, with integrated horn tweeter.
  • 25 cm (10") PA bass speaker of high power capability and high efficiency
  • Coaxially arranged horn tweeter with 25 mm (1", voice coil = 44 mm) high-frequency driver
  • Excellent sound characteristics
  • Robust diecast basket with rear-ventilated centering spider
  • 64 mm (2½") heat-resistant voice coil on a polyamide voice coil former (TIL)
  • Excellent and consistent radiation pattern
  • Ideally suited for stage monitors or very compact full range speaker systems
  • Operation only allowed with crossover network (recommended crossover frequency: >1,800 Hz)
Klang+Ton 02/2016
"The speaker system Studio 10 features a very neutral sound with great power reserves. Suitable as a studio monitor as well as for hi-fi applications of high requirements. The Studio 10 provides a well-balanced and neutral sound which achieves top results." (SP-310CX in a project from K+T)
Klang+Ton 02/2016
The SP-310CX applied in the Studio 10, a project from K+T:
"The speaker system Studio 10 features a very neutral sound with great power reserves. Poor recordings are not enhanced, high-quality recordings show their full potential - a perfect  tool!"
Klang+Ton 01/2016
"Despite its compact size, the thorough development resulted in a speaker system with a high power capability which can surely meet audiophile requirements. It is an ideal coaxial speaker for hi-fi and monitoring."
Antal
På fjernlager

Ref: SP-310CX

Impedance (Z) 2 x 8 _
Line technique -
Frequency range f3-3,000 Hz (bass)
1,000-22,000 Hz (tweeter)
Resonant frequency (fs) 60 Hz (bass), 700 Hz (tweeter)
Rec. crossov. frequ. (fmax.) (12 dB/oct.) -
Power rating 200 W (bass) / 50 W (tweeter)
Peak music power output 400 W (bass) / 100 W (tweeter)
Sensitivity 96 dB (bass) / 105 dB (tweeter)
Max. rated SPL -
Max. voltage -
Radiation angle, horizontal
Radiation angle, vertical
Suspension compl. (Cms) 0.24 mm/N
Moving mass (Mms) 32 g
Mech. Q factor (Qms) 3.24
Electr. Q factor (Qes) 0.36
Total Q factor (Qts) 0.32
Equivalent volume (Vas) 41 l
DC resistance (Re) 5.6 _
Force factor (BxL) 13.3 Tm
Voice coil induct. (Le) 0.65 mH
Voice coil diameter Ø 64 mm (bass) / Ø 44 mm (tweeter)
Voice coil former polyamide (TIL)
Linear excursion (XMAX) ±2.5 mm
Eff. cone area (Sd) 346 cm2
Magnet weight 1.6 kg
Magnet diameter Ø 156 mm/Ø 110 mm
Mounting cutout Ø 232 mm
Mounting depth 173.5 mm
Mounting hole diameter -
Hole spacing X-axis -
Hole spacing Y-axis -
Dimensions 263 x 263 x 188 mm
Outside diameter -
Width 263 mm
Height 263 mm
Depth 188 mm
Protective class
Admiss. ambient temp. 0-40 °C
Weight 6.24 kg
Sales unit 1
Type of speaker
SP-310CX
