LD Systems Active 8" 2-way bass-reflex PA Loudspeaker

4.379,00 kr.
Inkl. moms
STINGER 8 A G3

Engineered for rock-solid reliability day in, day out this active 2-way system is a truly professional performer. With its multi-purpose bass reflex construction and carefully contoured, user-friendly presets it is equally suitable for fullrange, satellite or floor monitor applications. The STINGER® 8 A G3 is powered by high efficiency Class D amplification with a hefty 300 watts RMS output. It drives a custom designed 8_ woofer and BMS compression driver delivering a punchy low end and smooth, crisp highs. The HF waveguide has been designed using BEM, the numerical modeling of sound radiation and propagation. It reduces floor and ceiling reflections, effectively eliminates side lobes and achieves a controlled uniform coverage pattern. The STINGER® 8 A G3 incorporates LD Systems_ proprietary DynX® DSP technology to ensure top-level performance with maximum clarity and punch at all times. Processing includes crossover and multiband limiter functions for accurate time alignment and pristine, distortion-free audio. Designed to be a real workhorse throughout, the enclosure is made of rigid birch ply and coated with ultra tough polyurea for extraordinary strength and durability. Sporting a steel front grille, Dual-Tilt pole receptacle, multiple suspension points and ergonomic handles the STINGER® 8 A G3 is an attractively priced choice for truly professional sound reinforcement. A large selection of accessories facilitate live and installed applications.

Antal
På fjernlager

Ref: LDEB82AG3

  • 2-way active 8_ bass reflex PA speaker
  • High-efficiency 300 watts RMS digital power stage and 129 dB max. SPL
  • Multi-purpose design for fullrange, satellite and monitor applications
  • Application presets for quick frequency response contouring
  • BEM optimized HF waveguide for uniform coverage
  • 8_ custom woofer and BMS compression driver
  • DynX® DSP technology for distortion-free performance
  • 2 line/mic input channels with individual gain controls plus mono mix out
  • 12 mm birch ply cabinet with ultra rugged polyurea finish and M10 suspension points
  • Shock-resistant front grill provides maximum speaker protection
  • 36 mm Dual-Tilt pole receptacle for 0° or 5° mounting angles
  • Large selection of smart installation and transport accessories

Product typePA loudspeaker
TypePowered
Low/mid Woofer dimensions8 "
Woofer dimensions (mm)203.2 mm
Woofer magnetFerrite
Woofer brandCustom-made
Woofer voice coil2 "
Woofer voice coil (mm)50.8 mm
HornBEM optimized CD Horn
HF driver dimensions1 "
HF driver dimention (mm)25.4 mm
HF driver magnetFerrite
HF driver brandBMS
HF driver voice coil1 "
HF driver voice coil25.4 mm
AmplifierClass D
Dispersion (H x V)90 x 50 °
System Power (RMS)300 W
Peak power600 W
Frequency response70 - 20000
Max. SPL (Peak)125 dB
Protection circuitsMultiband limiter
Protection circuitsover voltage
Protection circuitsover-current
Protection circuitsthermal overload
Input sensitivity-9 dBu
Controls2 x gain
Controls2 x Mic/Line
ControlsMode
IndicatorsLimit
IndicatorsMic
IndicatorsMode
IndicatorsOn
IndicatorsProtect (protection circuit engaged)
IndicatorsSignal
Line inputs2
Line input connectors6.3 mm jack
Line input connectorsXLR
Line outputs1
Line output connectorsXLR
Power supply100 - 120 V / 50 - 60 Hz or 200 - 240 V / 50 - 60 Hz (automatic switching)
Power supplySwitching power supply
Operating Temperature0 - 40 °C
Relative Humidity< 80% (non-condensing)
Cabinet material12 mm Plywood
Cabinet surfacePolyurea
Cabinet constructionBass Reflex
Width270 mm
Height457 mm
Depth290 mm
Weight10,5 kg
LD Systems
LDEB82AG3
