NEUTRIK PowerCon t/230V - NAC-3FCHC

219,00 kr.
Inkl. moms
NEUTRIK POWERCON plug
  • For mains connection with a high power rating of up to _ 250 V/32 A
  • Screw connections for ground, phase and neutral conductor
  • For cable cores: 2.5-6 mm2
  • Robust version with latching device and cable inlet with self-adjusting clamps
Antal
På fjernlager

Ref: NAC-3FCHC

Type plug
Type
Quantity 1
Features latching device
Colour/colour coding black
Power rating _ 250 V/32 A
Insulating resistance > 10 G_
Dielectric strength DC current  4 kV/_ 2.8 kV
Certification VDE, UL, cUL and JET
Pole number 2+PE
Cable inlet 8-20 mm
Connection screw terminals
Strain relief yes
Cable bending protection -
Stereo -
Mono -
Switches -
Material silver-plated bronze contacts, plastic
Central fixing -
Admiss. ambient temp. -25 °C to +70°C
Dimensions -
Diameter -
Length -
Weight 72 g
Other features -
NEUTRIK
NAC-3FCHC
