MONACOR Sender - TXA-800ST
Professional 16-channel Mono PLL Audio Transmission System, 863-865 MHz, with Extensive Accessories
- Compatible with portable amplifier systems of the TXA-800 and TXA-1000 series
- Can be combined with the TXA-800and TXA-1000 series, but also suitable as a tour guide system and for any other application in which a certain audio source or voice source is to be distributed to one or more receivers
- Can be combined with transmitters and receivers of the ATS-16 series
- Simultaneous operation of up to 8 transmitters with different frequencies (dep. on distance of transmitters, stationary RF sources of interference and other local conditions)
- Licence-free in the EU
16-channel PLL transmitter, for microphone operation and line audio signals.
Licence-free in the EU.
- Matching the receivers TXA-800R, ATS-16R and portable amplifiers of the TXA-800 series, TXA-1000 series, TXA-1020 series
- 16 selectable UHF frequencies (863.1-864.9 MHz)
- Audio stereo line input via RCA L/R
- Balanced XLR microphone input and 6.3 mm microphone input
- Audio mono line output via RCA
- Adjustable headphone output
- Backlit LCD for indicating channel/frequency, LEDs for carrier frequency, signal and signal peak
- Additional DC voltage output 10-15 V DC current for connecting an additional transmitter
- 482 mm (19") rack installation of 2 devices is possible with supplied mounting brackets
- Power is provided via enclosed plug-in power supply
- Dimensions: 215 x 50 x 210 mm
- Weight: 1.25 kg
Licence-free in the EU.
Pris
3.369,00 kr.
På fjernlager
