100V forstærker 1x960Wrms - PA-1960 MONACOR
search
  • 100V forstærker 1x960Wrms - PA-1960 MONACOR
  • 100V forstærker 1x960Wrms - PA-1960 MONACOR

MONACOR 100V forstærker 1x960Wrms - PA-1960

12.469,00 kr.
Inkl. moms
High-power mono PA amplifier
  • 1 x 960 W
  • Additional, adjustable priority input with switchable priority function
  • 100 V slave input for inserting the amplifier into a 100 V speaker line
  • Switchable 400 Hz high-pass filter 6 dB/oct.
  • 2 insertion facilities on the rear panel for optional modules with the following features:
    • PA-6FD: fault detection module
    • PA-6FM: fault monitoring module
  • Connection for external on/off switch (remote start)
  • Temperature-controlled fan, continuously adjustable
  • LED indication for fault, protect, clip, signal, priority
  • Mains operation or 24 V emergency power operation
Antal
På fjernlager

Ref: PA-1960

Channels 1
Zones -
Power rating 960 W
Power rating at 2 _ -
Power rating at 4 _ -
Power rating at 8 _ -
Power rating at 100 V 1 x 960 W
Power rating with 4 _ bridged operation -
Power rating with 8 _ bridged operation -
Peak music power output (PMAX) -
Output impedance 75 V/5.6 _, 85 V/7.2 _, 100 V/10 _
Inputs 0.775 V/60 k_, bal.
Attenuation factor -
Frequency range 35-20,000 Hz
Crossover network high-pass filter: 400 Hz, 6 dB/oct.
Crossover frequency -
Integrated limiter -
Equalizer bass -
Equalizer midrange -
Equalizer treble -
S/N ratio > 100 dB
Crosstalk attenuation -
THD < 0.4%
Power supply _ 230 V/50 Hz/2,600 VA,
DC current  24 V/80 A
Mains voltage _ 230 V
Mains frequency 50 Hz
Power consumption, operation 2,600 VA
Power consumption, standby -
Standby current -
Operating voltage (possible alternative) DC current  24 V
Power supply (possible alternative) -
Admiss. ambient temp. 0-40 °C
Dimensions 483 x 133 x 374 mm, 3 RS
Width 483 mm
Height 133 mm
Depth 374 mm
Rack spaces, RS 3
Weight 25 kg
Connections screw terminals (inputs)
screw terminals (speakers)
PA-1960
