. CC Pro Shop 8´´ højttaler - SP-202E MONACOR .
8´´ højttaler - SP-202E MONACOR
search
  • 8´´ højttaler - SP-202E MONACOR
  • 8´´ højttaler - SP-202E MONACOR

MONACOR 8´´ højttaler - SP-202E

319,00 kr.
Inkl. moms
Hi-fi bass-midrange speaker, 50 W, 4 _
  • Multi-purpose speaker
  • Foam surround
  • Replacement speaker for closed speaker systems
HOBBY HIFI 04/2013
"A very talented 2-way speaker, thanks to a very clean reproduction of the midrange. Despite a very attractive price, the SP-202E from MONACOR is ideally suited for 2-way applications and promises an excellent sound quality."
Antal
På fjernlager

Ref: SP-202E

Impedance (Z) 4 _
Line technique -
Frequency range f3-6,000 Hz
Resonant frequency (fs) 51 Hz
Rec. crossov. frequ. (fmax.) (12 dB/oct.) -
Power rating 50 W
Peak music power output 100 W
Sensitivity 93 dB/W/m
Max. rated SPL -
Max. voltage -
Radiation angle, horizontal -
Radiation angle, vertical -
Suspension compl. (Cms) 0.62 mm/N
Moving mass (Mms) 15 g
Mech. Q factor (Qms) 4.5
Electr. Q factor (Qes) 0.81
Total Q factor (Qts) 0.69
Equivalent volume (Vas) 39 l
DC resistance (Re) 3.85 _
Force factor (BxL) 4.86 Tm
Voice coil induct. (Le) 0.6 mH
Voice coil diameter Ø 25.5 mm
Voice coil former aluminium
Linear excursion (XMAX) ± 2.5 mm
Eff. cone area (Sd) 210 cm2
Magnet weight 570 g
Magnet diameter -
Mounting cutout Ø 183mm
Mounting depth 82mm
Mounting hole diameter Ø 192 mm
Hole spacing X-axis -
Hole spacing Y-axis -
Dimensions Ø 202 mm x 82 mm
Outside diameter Ø 202 mm
Width Ø 202 mm
Height -
Depth 82 mm
Protective class
Admiss. ambient temp. 0-40 °C
Weight 1.39 kg
Sales unit 1
Type of speaker 8"
SP-202E
