. LD Systems IMA 60 Installation Mixing Amplifier 65W @ 4 Ohms / 100 V / 70 V .
LD Systems IMA 60 Installation Mixing Amplifier 65W @ 4 Ohms / 100 V / 70 V
search
  • LD Systems IMA 60 Installation Mixing Amplifier 65W @ 4 Ohms / 100 V / 70 V
  • LD Systems IMA 60 Installation Mixing Amplifier 65W @ 4 Ohms / 100 V / 70 V
  • LD Systems IMA 60 Installation Mixing Amplifier 65W @ 4 Ohms / 100 V / 70 V
  • LD Systems IMA 60 Installation Mixing Amplifier 65W @ 4 Ohms / 100 V / 70 V

LD Systems IMA 60 Installation Mixing Amplifier 65W @ 4 Ohms / 100 V / 70 V

4.499,00 kr.
Inkl. moms
  • Line input for emergency signal with contact closure
  • 2 microphone/line input sockets with microphone/line switch and switchable 24 V phantom power
  • Switchable chime feature in Mic/Line 1 channel
  • 2 line inputs with RCA sockets and Bluetooth 4.0 interface (mono summed)
  • 65W Class-D Amplifier with Lo-Z / Hi-Z selector switch and 4 Ohm / 100V / 70V outputs
  • Balanced AUX line output with Music-Mix switch, for controlling external amplifiers, active subwoofers or music-on-hold systems
  • 4 priority levels for comprehensive integration options
  • Switchable auto standby mode for reduction of energy consumption
  • Intuitive control panel design for operation with capacitive controls for selecting music source and Bluetooth pairing
  • Universal wide-range switching power supply
Antal
På fjernlager

Ref: LDIMA60

Specifications

General
Product type
Installation mixer preamplifier
Emergency input
1 balanced line input
Mic/ line inputs
2
Mic-/ Line Input Connectors
2 unbalanced stereo line inputs, Bluetooth 4.0
Music sources
2 unbalanced stereo line inputs, Bluetooth 4.0
Line outputs
1
Reinforced Main Outputs
1 with output mode selector (Low-Z/High-Z)
Cooling
Convection
Priority levels
4
Emergency Input
Nominal input sensitivity
-15 dBu (Sine 1 kHz, gain max)
Nominal input clipping
20 dBu (Sine 1kHz)
Priority Contact closure
+5VDC normally open for dry contact
Connector
5-pin Terminal Block, pitch 5.08mm
Mic/Line inputs 1-2
Nominal input sensitivity Mic
Mic: -40 dBu (sine 1 kHz, gain max)
Nominal input sensitivity line
Line: -17 dBu (sine 1 kHz, gain max)
Nominal input clipping Mic
Mic: -5 dBu (Sine 1kHz)
Nominal input clipping line
Line +19dBu (Sine 1kHz)
Phantom power
+ 24V, 10mA switchable
Connector Mic/Line1
5-pin Terminal Block, pitch 5.08mm, XLR/6.3 mm jack
Connector Mic/Line 2
1 dual RCA Mono Summed, 3-pin Terminal Block, pitch 5.08mm, Pitch 5.08mm
Music inputs - CD/AUX
Nominal input sensitivity CD/AUX
- 6.22 dBV (Sine 1 kHz, Gain max)
Connector CD/AUX
2 x dual RCA Mono Summed
Amplifier Output
Amplifier Outputs
High-Z: 70V or 100V outputs, Low-Z: 4 ohm minimum load
Preamplifier input
5-pin Terminal Block, pitch 5.08mm
RMS Power ( W )
65 W (Continuous sine wave 1kHz, 4 ohm load)
Power ( Peak ) (W)
70 W (100 msec sine 1kHz Burst @ 4 ohm load)
Frequency range
20 Hz - 20 kHz (LO-Z, -3 dB), 60 Hz - 20 kHz (HI-Z, -3 dB)
Tone controlBass
+/-10 dB (100 Hz)
Tone control Treble
+/-10 dB (10 kHz)
Protection circuits
Audio Limiter, over-current, Short circuit, thermal overload
Aux Output
Connector AUX-output
3-pin Terminal Block, pitch 5.08 mm
Maximum gain
22 dB
Power Supply
Type
Switching power supply
Operating voltage
100 V AC - 240 V AC, 50 - 60 Hz
Power consumption (max.)
Line: -17 dBu (sine 1 kHz, gain max)
Idle power consumption
7.5 W (no signal input)
Standby power consumption
<1 W
Operating temperature ( non-condensing )
0°C - 40°C; < 85% humidity
General data
Time to Auto-standby
20 Min.
Dimensions (W x H x D) ( height with rubber feet )
210 (W)x 95 (H) x 266.76 (D)mm
Optional accessories
Rack mounting hardware
Weight
2,39 kg
LDIMA60
