YAMAHA 3-way powered loudspeaker with a 2_ HF, an 8 _ MF and a 15" LF - DZR315

21.159,00 kr.
Inkl. moms

Yamaha DZR315

  • 2000W 3-vejs Yamaha PA speaker.
  • 3 højtalere: 2" HF, 8" MF og 15" LF speaker.
  • D-klasse forstærkermodul.
  • 96kHz DSP output giver lyd af højeste kvalitet med lav latency.
  • Avanceret FIR-X tuning og filtrering minimer phase distortion.
  • D-contour bygning og gennemført beskyttelse af intern kredsløb.
  • Lavet af krydsfinertræ, der gør højtaleren let men hårdfør.
Antal
På fjernlager

Ref: CDZR315

Speaker type

3-way, Bi-ampled Powered Speaker, Bass-reflex

Frequency range (-10dB)

31Hz - 20kHz

Coverage area

H75_ x V50_

Components

LF

15" Cone, 3" Voice Coil, Neodymium magnet

MF

8" Cone, 1.5" Voice Coil, Ferrite magnet

HF

2" Voice Coil, 1" Throat Compression Driver, Titanium diaphragm, Neodymium magnet

Crossover

700Hz (FIR-X), 2.5kHz (Passive)

Sampling frequency rate

Internal

96kHz and FIR Filter

A/D D/A Converters

96kHz AD/DA

Maximum output level (1m; on axis)

143dB SPL *1

Power rating

Dynamic

2000W (LF:1000W, MF/HF: 1000W) *2

Continuous

1300W (LF: 920W, MF/HF: 380W)

I/O Connectors

Analog I/O

Analog IN: Combo x2, Line level (Maximum +24dBu), Input impedance 20k_, Analog OUT: XLR3-32 x2, CH1: THRU (fix), CH2: THRU or DSP OUT

Others

USB2.0 Host 5V 500mA for USB memory DATA storage/load

AC

IEC AC inlet x1 (V-Lock)

Amplifier class

Class-D

Cooling

Fan cooling, Variable speeds

Power consumption

45W (Idle), 150W (1/8)

Handle

Aluminium die-cast, Side x2

Rigging

M10 x16

Dimensions

W

550 mm (21.6")

H

897 mm (35.3") (with rubber feet)

D

520 mm (20.5")

Net weight

41.6kg (91.7lbs)

Options

Cover: SPCVR-DZR315

Others

Enclosure Material, Finish, Color: Plywood, Durable Polyurea Painting, Black

Yamaha
CDZR315
