Onkyo TX-8220 Stereo Receiver with Built-In Bluetooth

3.149,00 kr.
Inkl. moms

Universal connectivity meets pure analog amplification in a simple hub that sounds a whole lot better than its modest price suggests. All the essentials are covered with digital audio inputs for TV and BD/DVD player connection, along with an MM phono equalizer, four analog line-level inputs for CD player and everything else.

Antal
På fjernlager

Ref: TX-8220

Features

AMPLIFIER

Power Watts/Ch (6 Ohms 1kHz, 2 Ch Driven, FTC) 100, 0.10% THD
Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC) 45, 0.08% THD
Dynamic Power 140 W (3 Ohms, Front)
120 W (4 Ohms, Front)
80 W (8 Ohms, Front)
WRAT (Wide Range Amplifier Technology) _
H.C.P.S. (High Current Power Supply) -
Non-Phase-Shift Amp Design _ (for Realistic Sound Imaging)
6 Ohm Capable _
4 Ohm Capable _
Direct/Pure Mode _/-
384K/32 Bit DACs -
192K/24 Bit DACs _(PCM1754))

CONNECTIVITY

Audio Input/Output 4/1
Phono Input _
Digital Audio IN (Opt/Coax) 1/1
Auto Power On When Signal is Detected -
Zone 2 Line Out -
Zone 2 Digital to Analog Audio Conversion -
Speaker A/+B _
Subwoofer Pre-out _
Headphone Jack _
Bluetooth _ (Version 4.1, A2DP/AVRCP)
Internet Radio Capable -
Spotify Connect Support -
Streaming Audio From PC / Network -
Hi-Res Streaming Audio Formats -
Supports Onkyo Remote App -
Wireless Network -
USB Input -
AirPlay -
Firmware Updates via Network/USB _

MISCELLANEOUS

Quick Access BGM Presets -
Number of AM/FM Presets 40
Preset Station Naming _
Direct Access Tuning _
Automatic/Manual Tuning _
Sleep Timer _
IR Input -
IR Output -
RI-Compatible Remote Control _
Warranty 2 YEARS

Specs

AMPLIFIER SECTION

Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC) 45, 0.08% THD
Power Watts/Ch (6 Ohms 1kHz, 2 Channel Driven) 100, 10% THD
Dynamic Power 140 W (3 Ohms, Front) 120 W (4 Ohms, Front) 80 W (8 Ohms, Front)
THD + Noise 0.08 % (20hz-20kHz, Half power)
Frequency Response 10 Hz-100 kHz (+ 1 dB, -3 dB) (Direct Mode)
S/N Ratio 100 dB (IHF-A, Line In, Speaker Out) 93 dB ( IHF-A, Phono In, Speaker Out)
Phono Overload (1 kHz) 40 mV (MM, 1 kHz, 0.5%)

TUNER SECTION

FM 87.5 MHz_107.9 MHz
AM 530 kHz_1,710 kHz
FM/AM Preset Memory 40 Stations

GENERAL

Power Supply AC 120 V_, 60 Hz
Power Consumption 2.7 A
Standby Power Consumption 0.4 W
No-Sound Power Consumption 20 W
Network Standby Power Consumption 2.9 W
Dimensions (W x H x D) 17 1/8" x 5 7/8" x 12 15/16" (435 x 149 x 328 mm)
Weight 15.0 lbs. (6.8 kg)
TX-8220
