| Projector type |
1-Chip DLP_ projector |
|---|
| DLP_ Chip | Panel Size |
17.0 mm (0.67 in) diagonal (16:10 aspect ratio) |
|---|
| DLP_ Chip | Display Method |
DLP_ chip x 1, DLP_ projection system |
|---|
| DLP_ chip | Number of Pixels |
2,304,000 (1920 x 1200 pixels) |
|---|
| Light Source |
Laser diodes |
|---|
| Light output |
5,200 lm*1/5,400 lm (Center)*2 |
|---|
| Time until light output declines to 50 %*3 |
20,000 hours (NORMAL) |
|---|
| Resolution |
1920 x 1200 pixels |
|---|
| Contrast Ratio*1 |
20,000:1 (Full On/Full Off, Dynamic Contrast Mode: ON) |
|---|
| Screen size [diagonal] |
1.02_7.62 m (40_300 in), 16:10 aspect ratio |
|---|
| Center-to-corner zone ratio*1 |
90 % |
|---|
| Lens |
2.0x manual zoom (throw ratio: 1.46_2.94:1), manual focus, F 2.0_3.4, f 21.5_43.0 mm |
|---|
| Lens shift | Vertical(From the origin point of the lens mounter) |
+64 %, -44 % (manual) |
|---|
| Lens shift | Horizontal(From the origin point of the lens mounter) |
+34 %, -27 % (manual) |
|---|
| Keystone Correction Range |
Vertical: ±40 °, Horizontal: ±20 °. When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously,correction cannot be made exceeding a total of ±60 °. |
|---|
| Installation |
Ceiling/floor, front/rear, free 360-degree installation |
|---|
| Terminals | HDMI In |
HDMI 19-pin x 2 (Compatible with HDCP 2.2, Deep Color, 4K/60p signal input*4 ), CEC supported |
|---|
| Terminals | Computer 1 In |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR/YC) |
|---|
| Terminals | Computer 2 In/1 Out |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR/YC) |
|---|
| Terminals | Video In |
Pin jack x 1 (composite video) |
|---|
| Terminals | Audio In 1 |
Pin jack x 2 (L, R) |
|---|
| Terminals | Audio In 2/3 |
M3 x 1/M3 x 1 |
|---|
| Terminals | Audio Out |
M3 x 1 (Variable) |
|---|
| Terminals | Serial In |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
|---|
| Terminals | DIGITAL LINK |
RJ-45 x 1 for network and DIGITAL LINK connections (HDBaseT_ compliant), PJLink_ (Class 2) compatible, 100Base-TX, Art-Net compatible, HDCP 2.2 compatible, Deep Color compatible,4K/60p signal input*4 |
|---|
| Terminals | LAN |
RJ-45 x 1 for network connection, PJLink_ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
|---|
| Terminals | USB |
USB connector (Type A) x 1 (Output 5 V/2 A) |
|---|
| Power Supply |
AC 100_240 V, 50/60 Hz |
|---|
| Power Consumption |
TBD |
|---|
| Cabinet Materials |
Molded plastic |
|---|
| Operation noise*1 |
27 dB (Quiet Mode) (TBD), 32 dB (Normal Mode) (TBD) |
|---|
| Dimensions (W x H x D) |
498 x 168*5 x 492 mm (19 5/8_ x 6 5/8_*5 x 19 3/8_ ) |
|---|
| Weight*6 |
Approx. 16.3 kg (35.9 lbs) (TBD) |
|---|
| Operating Environment |
Operating temperature: 0_45 °C (32_113 °F),operating humidity: 10_80 % (no condensation) (TBD) |
|---|
| Applicable Software |
Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software |
|---|
| Note |
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards. Value is average of all products when shipped. *2 Average light-output value of all shipped products measured at center of screen in NORMAL Mode. *3 Aroundthis time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast contents, NORMAL Mode, Dynamic Contrast [ON], under conditions with 35 °C (95 °F), 700 m (2,297 ft) above sea level, and 0.15 mg/m3 of particulate matter. Estimated time until light outputdeclines to 50 % varies depending on environment. *4 4K signals are converted to the projector's resolution (1920 x 1200 pixels) upon projection. Supported terminals: DIGITAL LINK/HDMI®. *5 With legs at shortest position. *6 Average value. May differ depending on the actual unit. |
|---|
