| Projector type |
LCD projectors |
|---|
| LCD Panel | Panel Size |
16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
|---|
| LCD Panel | Pixels |
2,304,000 (1920 x 1200) pixels |
|---|
| Light Source |
Laser diode |
|---|
| Light Output*1 *2 |
7,000 lm |
|---|
| Time until light output declines to 50 %*3 |
20,000 hours (NORMAL/QUIET)/24,000 hours (ECO) |
|---|
| Resolution |
WUXGA (1920 x 1200 pixels) |
|---|
| Contrast Ratio*1 |
3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
|---|
| Screen Size (Diagonal) |
0.76_7.62 m (30_300 in), 16:10 aspect ratio |
|---|
| Center-to-corner zone ratio*1 |
85 % |
|---|
| Lens |
1.6x manual zoom (throw ratio: 1.09_1.77:1), manual focus lens, F 1.60_2.12, f 15.30_24.64 mm |
|---|
| Digital Zoom Extender *4 |
Throw ratio 1.09_2.21:15 (Corresponding value. When used together with optical zoom.) |
|---|
| Lens shift | Vertical (from center of screen) |
+44 %, 0 % (manual) |
|---|
| Lens shift | Horizontal (from center of screen) |
+20 %, -20 % (manual) |
|---|
| Keystone Correction Range |
Vertical: ±25 °, Horizontal: ±35 ° |
|---|
| Terminals | HDMI 1/2 IN |
HDMI 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p6 signal input), CEC supported |
|---|
| Terminals | Computer 1 In |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals | Computer 2 In |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals | AUDIO 1/2 IN |
M3 stereo mini-jack x 2 |
|---|
| Terminals | Variable Audio Out |
M3 stereo mini-jack x 1 |
|---|
| Terminals | Serial In |
D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
|---|
| Terminals | DIGITAL LINK/LAN |
RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT_ compliant), 100Base-TX (Compatible with PJLink_ [Class 2], HDCP, Deep Color, 4K/30p*6 signal input) |
|---|
| Terminals | LAN |
RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink_ [Class 2] |
|---|
| Terminals | USB(VIEWER/WIRELESS/DC OUT) |
USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module, power supply (DC 5 V, maximum 2 A*7 ) |
|---|
| Power Supply |
AC 100 V_240 V, 50/60 Hz |
|---|
| Power consumption*8 | Maximum power consumption |
420 W (4.5_1.9 A) (455 VA) (Power consumption is 410 W at 200_240 V) |
|---|
| Power consumption*8 | On-mode power consumption (Light Power)[Normal] |
390 W (100_120 V), 375 W (200_240 V) |
|---|
| Power consumption*8 | On-mode power consumption (Light Power)[Eco] |
275 W (100_120 V), 265 W (200_240 V) |
|---|
| Power consumption*8 | On-mode power consumption (Light Power)[Quiet] |
270 W (100_120 V), 260 W (200_240 V) |
|---|
| Filter*9 |
Included (Estimated maintenance time: approx. 20,000 hours) |
|---|
| Built in Speaker |
10 W monaural |
|---|
| Cabinet Materials |
Molded plastic |
|---|
| Operation noise*1 |
38 dB (NORMAL/ECO), 28 dB (QUIET) |
|---|
| Dimensions (W x H x D) |
399 mm x 115 mm x 348 mm (15 23/32_ x 4 17/32_ x 13 11/16_ ) (not including protruding parts) 399 mm x 133 mm x 348 mm (15 23/32_ x 5 1/4_ x 13 11/16_ ) (with feet at shortest position) |
|---|
| Operating Environment |
Operating temperature: 0_45 °C (32_113 °F)*11,*12 , Operating humidity: 20_80 % (no condensation) |
|---|
| Weight with supplied lens*10 |
Approx. 7.0 kg (15.43 lbs) |
|---|
| Applicable Software |
Multi Monitoring & Control Software, Logo Transfer Software, Presenter Light Software for Windows®*13, Wireless Projector App for iOS/Android_*14 |
|---|
| Note |
Note: Availability varies by country or region. *1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. *2 When [PICTURE MODE] is set to [DYNAMIC], [LIGHT POWER] is set to [NORMAL], [DAYLIGHT VIEW] is set to [OFF], and [AUTO POWER SAVE] is set to [OFF]. *3 Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of particulate matter). Estimated time until light output declines to 50 % varies depending on environment. *4 Resolution decreases when using this function. 6-Point Screen Correction, V/H Keystone Correction, and curved-screen correction are not available when using this function, and range of corner adjustment is limited. *5 When Digital Zoom Extender is set to 80%. *6 4K signals are converted to the projector's resolution upon projection. *7 On standby, power supply is available with Quick Startup set to ON or Power Management set to Ready. *8 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft). *9 Filter cleaning cycle varies depending on environment. Filter can be washed and reused up to two times. Filter cleaning cycle: 20,000 hours (under dust conditions of 0.08 mg/m3 ), 10,000 hours (under dust conditions of 0.15 mg/m3 ). *10 Average value. May differ depending on the actual unit. *11 Light output is limited at operating temperatures higher than 30 °C (86 °F), and projectors cannot be operated at altitudes higher than 2,700 m (8,858 ft) above sea level. *12 When optional AJ-WM50 Series wireless module is attached, operating temperature range becomes 0_40 °C (32_104 °F). *13 When using Presenter Light Software, images are projected with 1280 x 800 dots or 1024 x 768 dots onto the screen. Also, your PC display resolution may be forcibly changed, and audio playback disrupted or become noisy, while images and sound are being transmitted. *14 When using the Wireless Projector app, display resolution differs depending on your iOS/Android_ device and the display device. The maximum supported display resolution is WXGA (1280 x 800) |
|---|
