| Light output*1 |
6 000 lumens |
|---|
| Technology |
Laser LCD |
|---|
| LCD panel | Panel size (mm) |
16 mm diagonal (16:10 aspect ratio) |
|---|
| LCD panel | Panel size (inch) |
0.64 inch diagonal (16:10 aspect ratio) |
|---|
| LCD Panel | Display Method |
Transparent LCD panel (x 3, R/G/B) |
|---|
| LCD Panel | Drive Method |
Active matrix |
|---|
| LCD Panel | Pixels |
2,304,000 (1920 x 1200) x 3, total of 6,912,000 pixels |
|---|
| Lens |
1.6 x Manual zoom (throw ratio 1.09-1.77 :1), F = 1.60-2.12, f = 15.30-24.64 mm |
|---|
| Light Source |
Laser diode |
|---|
| Screen size (diagonal) (mm) |
0.76 - 7.62 m, 16:10 aspect ratio |
|---|
| Screen size (diagonal) (inch) |
30-300 in, 16:10 aspect ratio |
|---|
| Center-to-Corner Uniformity*1 |
85 % |
|---|
| Contrast*1 |
3,000,000:1 (all white/all black) (Input signals:PC,LIGHT POWER:NORMAL,PICTURE MODE:DYNAMIC,DAYLIGHT WIEW:OFF,DYNAMIC CONTRAST:1,AUTO POWER SAVE:OFF) |
|---|
| Resolution |
1920 x 1200 pixels |
|---|
| Optical axis shift | Vertical (from center of screen) |
0 % - +44 % (Manual) |
|---|
| Optical axis shift | Horizontal (from center of screen) |
- 20% - +20% (Manual) |
|---|
| Keystone correction range*2 |
Vertical: ±25°, Horizontal: ±35° |
|---|
| Installation |
Horizontal/Vertical, free 360-degree installation |
|---|
| Terminals | HDMI 1/2 IN |
HDMI 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p signal input) |
|---|
| Terminals | Computer 1 In |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals | COMPUTER 2 IN / MONITOR OUT |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) (input/output switching) |
|---|
| Terminals | Video In |
Pin jack x 1 |
|---|
| Terminals | AUDIO 1/2 IN |
M3 stereo mini-jack x 2 |
|---|
| Terminals | AUDIO 3 IN |
Pin jack (L/R) x 1 |
|---|
| Terminals | Variable Audio Out |
M3 stereo mini-jack x 1 |
|---|
| Terminals | Serial In |
D-sub 9-pin x 1 for computer control (RS-232C compliant) |
|---|
| Terminals | LAN |
RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink_ (Class 2) |
|---|
| Terminals | DIGITAL LINK/LAN |
RJ-45 x 1 for network and DIGITAL LINK connection, HDBase-T_ compliant, 100Base-TX, compatible with PJLink_ (Class 2), HDCP, Deep Color, 4K/30p signal input |
|---|
| Terminals | USB CONNECTOR |
USB connector (Type A) x 1 for Memory Viewer function, power supply (DC5V, maximum 2A*3), optional wireless module AJ-WM50 |
|---|
| Power Supply |
AC 100-240 V AC, 50/60 Hz |
|---|
| Power Consumption |
TBD |
|---|
| Built-in Speaker |
10 W (monaural) |
|---|
| Operating noise*1 |
NORMAL: 37dB, QUIET: 27dB |
|---|
| Cabinet Materials |
Molded plastic |
|---|
| Filter |
Included Filter cleaning cycle: 20,000 hours (0.08 mg/m3 of particulate matter), 10,000 hours (0.15 mg/m3 of particulate matter) |
|---|
| Dimensions (W x H x D) (mm) |
399 x 115 x 348 mm (Not including protruding parts)399 x 133 x 348 mm (With feet at shortest position) |
|---|
| Dimensions (W x H x D) (inch) |
15 23/32 x 4 17/32 x 13 11/16 inch (Not including protruding parts)15 23/32 x 5 1/4 x 13 11/16 inch (With feet at shortest position) |
|---|
| Weight (kg)*4 |
Less than 7.2 kg |
|---|
| Weight (lbs.)*4 |
Less than 15.87 lbs. |
|---|
| Operating environment (_/M) |
Operating temperature: 0 °C- 45 °C, operating humidity: 20 %-80 % (no condensation) |
|---|
| Operating environment (°F/Feet) |
Operating temperature: 32 °F -113 °F, operating humidity: 20 %-80 % (no condensation) |
|---|
| Applicable software/application |
Logo Transfer Software, Multi Monitoring & Control Software, Presenter Light for Windows®, Wireless Projector Apps for iOS/Android_ |
|---|
| Note |
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards. Value is average of all products when shipped. *2 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast contents, NORMALMode, Dynamic Contrast [2], under conditions with 30 °C (86 °F), 700 m (2,297 ft) above sea level, and 0.15 mg/m3 of particulate matter. Estimated time until light output declines to 50 % varies depending on environment. *3 On standby, power supply is available with Quick Startup set to ON or Power Management set to Ready. *4 Average value. May differ depending on the actual unit. |
|---|
| Light output |
6 000 lumens |
|---|
