| Projector type |
LCD projectors |
|---|
| LCD panel | Panel size (mm) |
19.3 mm diagonal (16:10 aspect ratio) |
|---|
| LCD panel | Panel size (inch) |
0.76 inch diagonal (16:10 aspect ratio) |
|---|
| LCD Panel | Display Method |
Transparent LCD panel (x 3, R/G/B) |
|---|
| LCD Panel | Drive Method |
Active matrix |
|---|
| LCD Panel | Pixels |
2,304,000 ( Pixels 1920 x 1200) pixels x 3 |
|---|
| Light Source |
Laser diodes |
|---|
| Light Output*1 *2 |
6,000 lm |
|---|
| Resolution |
WUXGA (1920 x 1200 pixels) |
|---|
| Contrast Ratio*1 |
3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1] or [2]. HDMI signal input) |
|---|
| Screen size (diagonal) (mm) |
1.02_10.16 m (40_400 in), 1.52_10.16 m (60_400 in) with the ET-ELW22, 2.54_10.16 m (100_400 in) with the ET-ELU20, 16:10 aspect ratio |
|---|
| Screen size (diagonal) (inch) |
1.02_10.16 m (40_400 in), 1.52_10.16 m (60_400 in) with the ET-ELW22, 2.54_10.16 m (100_400 in) with the ET-ELU20, 16:10 aspect ratio |
|---|
| Center-to-corner zone ratio*1 |
85 % |
|---|
| Lens |
Powered zoom (throw ratio 1.61_2.76:1), powered focus F = 1.7_2.3, f = 26.8_45.5 mm (for supplied lens; optional lenses also available) |
|---|
| Lens shift | Vertical(From the origin point of the lens mounter) |
±67 % (powered) (for supplied lens; optional lenses also available*4) |
|---|
| Lens shift | Horizontal(From the origin point of the lens mounter) |
±35 % (powered) (for supplied lens; optional lenses also available*4) |
|---|
| Keystone Correction Range |
Vertical: ±25 °, Horizontal: ±30 ° (for supplied lens; optional lenses also available*4) |
|---|
| Installation |
Ceiling/floor, front/rear, free 360-degree installation |
|---|
| Terminals | HDMI In |
HDMI 19-pin x 3 (Compatible with HDCP 2.3, Deep Color, 4K/60p*5 signal input), CEC supported |
|---|
| Terminals | Computer In |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals | Monitor Out |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals | Serial / Multi Sync In |
D-sub 9-pin (female) x 1 for external control/link control (RS-232C compliant) |
|---|
| Terminals | Multi Sync Out |
D-sub 9-pin (male) x 1 for link control |
|---|
| Terminals | REMOTE 1 IN |
M3 stereo mini-jack x 1 for wired remote control |
|---|
| Terminals | Remote 2 In |
D-sub 9-pin (female) x 1 for external control (parallel) |
|---|
| Terminals | Audio In |
M3 stereo mini-jack x 1 |
|---|
| Terminals | Audio Out |
M3 stereo mini-jack x 1 |
|---|
| Terminals | DIGITAL LINK |
RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT_ compliant), 100Base-TX (Compatible with PJLink_ [Class 2], Art-Net, HDCP 2.3, Deep Color,4K/60p*5 *6 signal input) |
|---|
| Terminals | LAN |
RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink_ [Class 2], Art-Net) |
|---|
| Terminals | DC Out |
USB Connector (Type A) x 1 (Output 5 V/2 A) |
|---|
| Power Supply |
AC 100_240 V, 50/60 Hz |
|---|
| Power Consumption*7 | Maximum power consumption |
360 W (4.2_2.0 A) (395 VA)(Power consumption is 345 W at 200_240 V) |
|---|
| Power Consumption*7 | On-mode power consumption (Light power) |
[NORMAL]: 330 W (100_120 V), 315 W (200_240 V)[ECO]: 240 W (100_120 V), 230 W (200_240 V)[QUIET]: 238 W (100_120 V), 228 W (200_240 V) |
|---|
| Cabinet Materials |
Molded plastic |
|---|
| Filter |
Included (Estimated maintenance time: approx. 20,000 hours) |
|---|
| Operation noise*1 |
32 dB (NORMAL/ECO), 26 dB (QUIET) |
|---|
| Dimensions (W × H*8 × D) |
561 x 224 x 439 mm (22 3/32_ x 8 13/16_ x 17 9/32_ ) (with supplied lens) |
|---|
| Weight*9 |
Approx. 17.6 kg (38.8 lbs) (with supplied lens) |
|---|
| Operating Environment |
Operating temperature: 0_45 °C (32_113 °F)*10, operating humidity: 20_80 % (no condensation) |
|---|
| Applicable software/application |
Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Smart Projector Control for iOS/Android_, Geometry Manager Pro*11 |
|---|
| Note |
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. *2 When [PICTURE MODE] is set to [DYNAMIC] and [LIGHT POWER] is set to [NORMAL]. *3 Around this time, light outputwill have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2]). Estimated time until light output declines to 50 % varies depending on environment. *4 Lens-shift range and keystone correction range may vary depending on lens.*5 4K signals are converted to the projector's resolution (1920 x 1200 pixels) upon projection. *6 YPBPR4:2:0 format only for 4K/60p signals input via DIGITAL LINK. *7 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards.On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft).*8 With legs at shortest position.*9 Average value. May differ depending on the actual unit. *10 Note that the projector cannot be used at altitudes 2,700 m (8,858 ft) or higher abovesea level. In the following operating environments, light output may be reduced to protect the projector: when the projector is used at altitudes below 700 m (2,297 ft) and ambient temperature is 38 °C (100 °F) or higher; when the projector is used at altitudes between 700 m (2,297 ft) and1,400 m (4,593 ft) exclusive and ambient temperature is 36 °C (97 °F) or higher; when the projector is used at altitudes between 1,400 m (4,593 ft) and 2,100 m (6,890 ft) exclusive and ambient temperature is 34 °C (93 °F) or higher; and when the projector is used at altitudes between2,100 m (6,890 ft) and 2,700 m (8,858 ft) exclusive and ambient temperature is 32 °C (90 °F) or higher. *11 Some functions available in Geo Pro software are not supported by the PT-MZ880 Series. |
|---|
