| Projector type |
LCD projectors |
|---|
| LCD Panel | Panel Size |
16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
|---|
| LCD Panel | Pixels |
2,304,000 (1920 x 1200) pixels |
|---|
| Light Source |
Laser diodes |
|---|
| Light Output*1 *2 |
4,200 lm |
|---|
| Time until light output declines to 50 %*3 |
20,000 hours (NORMAL/QUIET)/24,000 hours (ECO) |
|---|
| Resolution |
WUXGA (1920 x 1200 pixels) |
|---|
| Contrast Ratio*1 |
3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
|---|
| Screen Size (Diagonal) |
0.76_7.62 m (30_300 in), 16:10 aspect ratio |
|---|
| Center-to-corner zone ratio*1 |
85 % |
|---|
| Lens |
1.2x manual zoom (throw ratio: 1.36_1.64:1), manual focus lens, F 1.61_1.76, f 19.1_23.0 mm |
|---|
| Digital Zoom Extender *4 |
Throw ratio: 1.36_2.05:1*5 (Corresponding value. When used together with optical zoom.) |
|---|
| Keystone Correction Range |
Vertical: ±25 ° (Auto, Manual), Horizontal: ±35 ° (Manual) |
|---|
| Terminals | HDMI 1/2 IN |
HDMI 19-pin x 2 (Compatible with HDCP 1.4, Deep Color, 4K/30p*6 signal input), CEC supported*7 |
|---|
| Terminals | Computer 1 In |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals | Computer 2 In |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals | AUDIO 1/2 IN |
M3 stereo mini-jack x 2 |
|---|
| Terminals | Audio Out |
M3 stereo mini-jack x 1 |
|---|
| Terminals | Serial In |
D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
|---|
| Terminals | LAN |
RJ-45 x 1 for network control, 10Base-T, 100Base-TX |
|---|
| Terminals | USB(VIEWER/WIRELESS/DC OUT) |
USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module, power supply (DC 5 V, maximum 2 A*8) |
|---|
| Protocol versions |
IPv4 |
|---|
| Power Supply |
AC 100 V_240 V, 50/60 Hz |
|---|
| Power Consumption*9 | Maximum power consumption |
240 W |
|---|
| Power Consumption*9 | On-mode power consumption (Light Power) |
[NORMAL]: 215 W (100_240 V), 205 W (200_240 V)[ECO]: 165 W (100_240 V), 160 W (200_240 V)[QUIET]: 160 W (100_240 V), 155 W (200_240 V) |
|---|
| Built in Speaker |
10 W monaural |
|---|
| Filter*10 |
Included (Estimated maintenance time: approx. 20,000 hours) |
|---|
| Operation noise*1 |
33 dB (NORMAL/ECO),23 dB (QUIET) |
|---|
| Dimensions (W x H x D) |
349 mm x 105 mm x 309 mm (13 3/4_ x 4 1/8_ x 12 5/32_ ) (with feet at shortest position) |
|---|
| Weight with supplied lens*11 |
Approx. 4.2 kg (9.26 lbs) |
|---|
| Operating Environment |
Operating temperature: 0_45 °C (32_113 °F)*12, Operating humidity: 20_80 % (no condensation) |
|---|
| Applicable Software |
Multi Monitoring & Control Software, Projector Network Setup Software, Logo Transfer Software, Presenter Light Software for Windows®*13, Wireless Projector App for iOS/Android_*14 |
|---|
| Note |
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. *2 When [PICTURE MODE] is set to [DYNAMIC], [LIGHT POWER] is set to[NORMAL], [DAYLIGHT VIEW] is set to [OFF], and [AUTO POWER SAVE] is set to [OFF]. *3 Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2],temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of particulate matter). Estimated time until light output declines to 50 % varies depending on environment. *4 Resolution decreases when using this function. V/H Keystone Correctionand curved-screen correction are not available when using this function, and range of corner adjustment is limited. *5 When Digital Zoom Extender is set to 80 %. *6 4K signals are converted to the projector's resolution upon projection. *7 Depending on theconnected CEC command-compatible device, the link control may not operate normally. *8 On standby, power supply is available with Quick Startup set to ON or Power Management set to Ready. *9 Measurement, measuring conditions, and method ofnotation all comply with ISO/IEC 21118: 2020 international standards. On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft). *10 Filter cleaning cycle varies depending on environment. Filtercan be washed and reused up to two times. Filter cleaning cycle: 20,000 hours (under dust conditions of 0.08 mg/m3), 10,000 hours (under dust conditions of 0.15 mg/m3). *11 Average value. May differ depending on the actual unit. *12 Light output islimited at operating temperatures higher than 30 °C (86 °F), and projectors cannot be operated at altitudes higher than 2,700 m (8,858 ft) above sea level. When optional AJ-WM50 Series Wireless Module is attached, operating temperature range becomes0_40 °C (32_104 °F). *13 When using Presenter Light Software, images are projected with 1280 x 800 dots or 1024 x 768 dots onto the screen. Also, your PC display resolution may be forcibly changed, and audio playback disrupted or become noisy, whileimages and sound are being transmitted. *14 When using the Wireless Projector app, display resolution differs depending on your iOS/Android_ device and the display device. The maximum supported display resolution is WXGA (1280 x 800). |
|---|
| Control function via LAN |
PJLink_ [Class 2], Crestron Connected_, AMX Device Discovery |
|---|
