AMPIRE 2-Channel Digital Class D Amplifier
search
  • AMPIRE 2-Channel Digital Class D Amplifier
  • AMPIRE 2-Channel Digital Class D Amplifier
  • AMPIRE 2-Channel Digital Class D Amplifier
  • AMPIRE 2-Channel Digital Class D Amplifier
  • AMPIRE 2-Channel Digital Class D Amplifier

AMPIRE 2-Channel Digital Class D Amplifier

1.499,00 kr.
1.199,00 kr. Spar 300,00 kr.
Inkl. moms
Antal
Sidste elementer på lager

Ref: MBM100.2-2G

MBM160.2
- 2-Channel Digital Amplifier
- Ultra-Compact Design
- Cinch & balanced Speaker Inputs
- 320 Watt RMS/640 Watt max.
- Illuminated AMPIRE Logo

Specification:
Power Supply
Power supply voltage: 10 - 16 VDC
Idling current: 0,68A
Idling current when off: <0,4mA

Amplifier Stage
Output power (RMS) @ 14,4V / 4 Ohm: 70 Watt x 2
Output power (RMS) @ 14,4V / 2 Ohm: 100 Watt x 2
Output power (RMS) @ 14,4V / 4 Ohm: 200 Watt x 1 (bridged)
Output power (max.) @ 14,4V / 4 Ohm: 140 Watt x 2
Output power (max.) @ 14,4V / 2 Ohm: 200 Watt x 2
Output power (max.) @ 14,4V / 4 Ohm: 400 Watt x 1 (bridged)
Distortion (THD): <0,5%
S/N Ratio: >90dB
Channel separation: >65dB
Input sensitivity: 200mV - 6,0V

Filters
Low pass filter/slope: 50Hz - 250Hz / 12dB
High pass filter/slope: 50Hz - 250Hz / 12dB
Bass Boost/Frequency: 0 - 12dB @ 50Hz
Subsonic Filter: 25Hz.

Other Functions
Fuse: 20A x 1
Max size (LxWxH): 200 x 141 x 50mm
Weight: 1,35Kg
Inputs: RCA x2, High Level x2 (High Level Auto Turn On)
